VL53L0X Time of Flight Distance Sensor - ~30 to 2000mm Maximize

VL53L0X Time of Flight Distance Sensor - ~30 to 2000mm

VL53L0X Time of Flight Distance Sensor which measures what the distance of the item directly in front of the invisible beam is in a range of ~30 to 2000mm. High resolution TOF (Time of Flight) sensor for measuring the time it takes the light emitted from the sensor to travel to the object, hit it and be reflected back.

More details

Availability: IN STOCK

View Product Location Store Map
Tinkersphere

TS2236

$14.49

Features:

  • VL53L0X Time of Flight Sensor
  • Meausures the "Time of Flight" (TOF) which is the time it takes the light beam emitted to travel to the object, hit it, and come back.
  • This distance sensor allows the camera to focus instantly in both shooting and continuous shooting modes, maintaining the same performance even in low light or low contrast conditions
  • High resolution of
  • Operating Voltage: 2.8V to 5V
  • Accuracy: ± 3%
  • Detection Distance: approx 30mm to 2000mm
  • Communication Protocol: I2C Serial
  • Ranging time: less than 30ms
  • Power consumption: 20mW
  • Standby power consumption: 5μA
  • Internal Laser wavelength: 940nm non-visible light and does not harm the eyes
  • PCB size: about 13.3mm x 10.5mm ( 0.51" x 0.43" )
  • Easy to use with 6 pins via I2C interface
  • STMicroelectronics chipset with a full set of API drivers and technical documentation to make system integration quick and easy on virtually any microcontroller.
  • Module completes the distance calculation within and provides calculated distance in the I2C bus output data so your microcontroller can perform minimum calculations
  • Applications: VL53L0X sensing capabilities can support a variety of functions, including a variety of innovative user interface gesture sensing or proximity detection; sweeping robots and other appliances, wall detection, cliff detection, collision detection; faucets, soap dispensers, Dry cell phones and irrigators; laptop user presence detection; power switch monitors, unmanned aerial vehicles and IoT products
  • Compatible with Raspberry Pi and Arduino based systems
